Compressor Skid
 |
M/s. Gas Projects (I) Pvt. Ltd.’s Compressor Skid are factory
assembled Compressor and Motors constructed as a
Compressor Skid for compressing solution.The Skid is
designed and manufactured to ease of installation and
operation.
Compressor Skid is designed to standard unloading
requirements and customer built requirements which suits
industrial requirements.
Compressor Skids can be used for transfer operations and
gas evacuation operations. |
|
| |
| Features |
| • |
|
Ease of installation |
| • |
|
Dynamically balance and tested |
| • |
|
Standardised Hardware |
| • |
|
Minimal Maintenance |
|
| |
| Key features of compressor |
| • |
|
Designed for continuous duty |
| • |
|
Deep finned cast iron cylinders |
| • |
|
Aluminium cooler tubes and aerodynamically designed fan for efficient cooling |
| • |
|
Knockout drum conforming to ASME design |
| • |
|
Sturdy, robust case iron crankcase |
| • |
|
Forged steel crankshaft |
| • |
|
Optimal operating speed |
| • |
|
Pressure relief valve for extra safety |
| • |
|
Low expansion aluminium alloy piston |
|
| |
 |
| |
| Service |
Compressor
Model |
Motor Capacity
In Hp |
Flow Rate
(M3/HR) |
Displacement At
600 Rpm (CEM) |
Shipping Weight
In Kg. |
| LPG / Propane |
91 |
5 |
7 |
4 |
315 |
| LPG / Propane |
291 |
7.5 |
14 |
8 |
460 |
| LPG / Propane |
491 |
15 |
30 |
17.2 |
760 |
| LPG / Propane |
691 |
25 |
50 |
29.2 |
1625 |
|
| |
